Buildings
Smartlink Engineering Sdn Bhd
- Located at Bukit Kemuning, Shah Alam
- 45 mins from KL International Airport
- Building with 25,000 sqf of total build-up area
- 1800 sqf of Cable Harness production
- 1800 sqf of Module Assembly production
- 2400 sqf of Machine Assembly production
- Clean environment with Epoxy flooring
- Dedicated & experienced workforce with IPC620 certification
Smartlink Engineering Penang Sdn Bhd
- Located at Diamond Valley Industrial Park, Penang island
- 15 to 20 min from Penang International Airport
- 2,700 sqf. production and store
- Production system set up for high mix low volume mode
- Dedicated & experienced workforce and trained according to IPC620 certification
Toolshop Facilities
- 2,700 sqf. – Toolshop and QA
- Clean environment (Epoxy flooring)
- To support the module assembly and system integration business
- Dedicated & experienced workforce with GD & T knowledge
| Description | Capacity (mm) | Accuracy |
|---|---|---|
| Vertical CNC Machining Center | Z460, X762, Y410 | ± 0.01mm |
| Vertical CNC Machining Center | Z560, X1050, Y540 | ± 0.01mm |
| Master Cam | - | - |
| Vertical Milling | Z406, X900, Y450 | ± 0.05mm |
| Precision Grinding | X450, Y150 | ± 0.01mm |
| Turning | Ø 300 x 1000 | ± 0.02mm |
| Cutter Grinding | - | - |
| Drill Bit Re-shaping | - | - |
| Band Saw | - | - |
| Chamfering | - | - |
| Air Tap (M2 to M10) | - | - |
| ARC Welding Set | - | - |
| Digital Height Gauge | 0 - 535 | 0.002mm |
| Digital Venier Caliper | 0 - 300 | 0.005mm |
| Venier Caliper | 600 & 1000 | 0.1mm |
| Granite Table | 1000 x 1000 & 450 x 450 | Grade 00 |
| Depth Micrometer | 0 - 25 | 0.01mm |
| Dial Test Indicator | 0 - 0.2 & 0.8 | 0.002 / 0.01mm |
| Plain Plug Gauge | Ø 2.99 - Ø 12.015 | Grade H7 |
| Thread Gauge | M3 x 0.5 - M12 x 1.75 | Grade H6 |
| Feeler Gauge | 0.03 - 0.8 | STANDARD |
| Pitch Gauge | 4 - 60 TPI | STANDARD |
| Chamfer Gauge | C0.5 - C15 | STANDARD |
| Thread Gauge | G 1/8" - G 3/8" | ISO |
| Outside Micrometer | 0 - 25 | 0.01mm |
| Outside Micrometer | 25 - 50 | 0.01mm |
| Outside Micrometer | 50 - 75 | 0.01mm |
| Outside Micrometer | 75 - 100 | 0.01mm |
| Block Gauge Set | 1.005 - 10 | Grade 1 |
Wire Harnessing Facilities
- Automatic Cut & Strip Machine
- Semi-Auto Crimping Machine
- Semi-Auto Stripping Machine
- Continuity Cable Harness Tester
- Sensor Tester
- Pull Test Equipment
- Crimping Tools
- Cutting Tools
- Standard Testing Meter
- ESD Facilities
